Aquastats

Johnson Controls, Electronic thermostat -30 to 212 degree
7416206

Penn Aquastat
7416215
7416225


H2O #	Manf. #	Description
7416205	A319ABC2401	Electronic thermostat -20 to 100 degree, SPDT 120/240, 16 AMP @ 120 V. adjustable differential (1 to 30 degree) Note 1 & 2
7416206	A419ABC-1C	Electronic thermostat -30 to 212 degree ( good choice ) Note 1 & 2 & 3
7416215	A19ABC-24	Penn aquastat 30 to 100 degree, SPDT 120/240, 8ft capillary with 5/16": bulb Note 1 & 2
7416225	A19ABC4	Penn aquastat 50 to 130 degree, SPDT 120/240, 8ft capillary with 5/16": bulb Note 1 & 2 & 3

Note 1 - Commonly used as heat limiting device to turn pumps off when they are left running by a spa user. Pumps left on for extended periods can transfer heat from the pump motor into the water which increases water temperature in the spa enough to melt PVC plumbing.

Note 2 - Commonly used as freeze protection to activate and de-activate spa pump(s) at a pre-set temperature.

Note 3 - Can be used as heater thermostat since temperature range exceeds 100 degrees

Thermostat


H2O #	Manf. #	Description
7416235	275-3123-00	Thermostat, SPST, 25 AMP, 12" X 1/4" bulb
7416255	275-3124-00	Thermostat, SPST, 25 AMP, 36" x 1/4" bulb
7416265	275-2720-00	Thermostat, SPST, 25 AMP, 48" x 1/4" bulb
7416285	275-3127-01	Thermostat, SPST, 25 AMP, 30" X 5/16" bulb
7416295	34-0030	Thermostat, SPST, 25 AMP, 36" X 5/16" bulb
7416305	072022	Thermostat, SPST, 25 AMP, 60" X 5/16" bulb
9813208	3-05-0001	Thermostat, SPDT, 25 AMP, 36" X 5/16" bulb, Long Probe Fits all Ramco Topsides, Spaded connections

Gas Heater Thermostat

unavailable


H2O #	Manf. #	Description
7416315	003346F	RayPak gas heater thermostat
9892104	R0318800	Laars millivolt thermostat kit
9892200	R0058200	Laars, E-971 electronic thermostat kit
