Pressure Switches |
|
 |
|
|
|
H2O # |
Manf. # |
Description |
|
1/8" NPT
Threaded
|
|
7408227 |
RayPak
#006737F |
Barksdale, SPST, 3
AMP, .5 to 5 PSI,
Plastic 1/8" NPT
with extended throat |
|
7408285 |
Pentai
#71957 |
Len Gordon,
DPST, 25 AMP,
Metal 1/8" NPT
Used on Purex Islander
Electric Heaters (renamed Manatee)
|
|
7408305 |
Tecmark
#3010 |
Tecmark, SPST, 25 AMP,
Metal
1/8" NPT,
very popular pressure switch used in electric heaters
|
|
7408344 |
Tecmark
#3902 |
Tecmark, SPST, 1 AMP, 1 to 5 PSI,
Plastic 1/8" NPT
|
|
7408347 |
Tecmark
#4010P |
Tecmark, SPST, 25 AMP,
Plastic
1/8" NPT,
The plastic version of the Tecmark
#3010 |
|
7408372 |
Balboa
#36142 |
Tecmark, #3903-EADE, SPST, 1 AMP, 1 to 5 PSI,
Plastic 1/8" NPT,
set at 2 PSI |
|
9764114 |
Pentair
#471097 |
Len Gordon, DPST, 25 AMP,
Plastic 1/8" NPT,
set at 2
PSI, Universal Switch
|
|
1/8" NPT
Threaded with Brass Adapters |
|
7408205 |
Tecmark
#3902 |
Tecmark, SPST, 1 AMP, 1 to 5 PSI,
Plastic 1/8" NPT with
adapters for barb fitting, 1/4" and 3/16" compression |
|
7408225 |
RayPak
#062237B |
Barksdale, SPST, 3
AMP, .5 to 5 PSI,
Metal 1/8" NPT with 1/4"compression adapter and terminal connectors |
|
7408350 |
Len Gordon
#800220-0 |
Len Gordon,
SPDT, 25 AMP, Plastic
1/8" NPT
with
adapters for barb fitting, 1/4" and 3/16" compression,
Low Profile,
Universal Switch
|
|
Compression Fitting |
|
9892123 |
Laars
#R0013200 |
Laars, SPST, 2 AMP,
Brass
3/16"
compression,
set at 2 PSI |
|
7408265 |
Pentair
#071580 |
Barksdale, SPST, 3
AMP, .5 to 5 PSI, Brass 1/4"
Compression
(sleeve and nut not included) |
|
1/4" MIP
Threaded |
|
9764037 |
Pentair
#470190 |
Barksdale, SPST, 3 AMP, .5 to 5 PSI,
Brass 1/4"
MIP,
Used on
Mini-Max Plus Gas Heaters |
|
9764962 |
Pentair
#471672 |
Tecmark, SPST, Plastic 1/4" MIP,
Used on MiniMax NT Gas Heaters |
7408285
9764114
7408350
9892123
9764037
 7408347
Note that
 has
been replaced with
9764962 |
|
Flow Switches |
|

|
|
|
|
H2O # |
Manf. # |
Description |
|
7408220 |
57-F3-2500-WHT |
M-25 Grid flow switch, 25 AMP, 1-1/2" S x 1-1/2" S
|
|
7408230 |
60-1008 |
Harwil Q-12 flow sensor with cord connector and 1/2" threaded adapter, will replace Harwil Q-12DS, Q-8DSA, Q-9DSP and Aqualarm 206-PVC-NOS and 206-PVC-NOT
(may need PVC Tee or bushing)
|
|
|
|
|
