Mini-Max 100 Gas Heater -
Pentair |
|
Data Sheet
Owners Manual
|
|
The MiniMax® 100 is a compact, lightweight and efficient gas fired high
performance aboveground pool and spa heater. It has a fuel gas input of
100,000 btu/hr with thermal efficiency in excess of 82%. Heater can be connected to
schedule 40 CPVC or ABS pipe and has a built-in top. Two models to
choose from, Millivolt version with standing pilot or Electronic version
with direct-spark ignition. Both are available in propane or natural gas
versions. Electronic heaters require 115 or 230 volt power source.
The MiniMax® 100 comes standard with Bronze headers. |
|
|
|
Millivolt Models |
|
H2O # |
Manf. # |
Description |
|
2230113 |
460352 |
Millivolt,
Natural, 100,000 BTU |
|
2230117 |
460353 |
Millivolt,
Propane, 100,000 BTU |
Electronic Models |
|
H2O # |
Manf. # |
Description |
|
2230105 |
460347 |
Electronic,
Natural, 100,000 BTU |
|
2230109 |
460348 |
Electronic,
Propane, 100,000 BTU |
Specifications: |
|
Model |
BTU |
Height* |
Width |
Depth |
|
Mini-Max 100 |
100,000 |
25.50" |
19.25" |
15.50" |
|
*
height with low profile top, add stack height if stack kit is needed |
|
|
Vent Kits for Mini-Max 100
- Pentair |
|
unavailable |
|
Mini-Max 100 comes shipped with low profile outdoor top.
For indoor or high wind outdoor installations, choose appropriate vent kit below.
|
|
Vent Kits |
|
H2O # |
Manf. # |
Description |
|
2230121 |
471187 |
100 indoor vent kit |
|
2230122 |
471357 |
100 outdoor high
wind top |
Specifications: Mini-Max 100 Vent Kits |
|
Manf. # |
Style |
Height* |
Vent Diameter |
|
471187 |
Indoor |
15-3/16" |
5" |
|
471357 |
Outdoor, high wind |
10-15/16" |
5" |
|
*
height is stack only, add heater height for total height |
|
|
